Mini Dumper is a small engineering/agricultural transportation equipment used for short distance handling and self dumping of materials In scenarios where large vehicles are difficult to enter and manual handling efficiency is low, loading, transportation, and unloading can be completed with a smaller body to reduce labor costs and improve efficiency.
Common transportation materials
Working principle
Technical Parameters
|
Engine |
||
| 动力型号： | Engine Model | Briggs&StrattonPioneer |
| 动力种类： | Engine Type | Single cylinder, OHV, 4-stroke, air cooling |
| 总排气量(ML)： | displacement | 203CC |
| 额定功率(kw/rpm)： | Rated Power | 6.5HP/3600rpm |
| 燃油种类： | Fuel Type | 92 # Gasoline |
| 燃油消耗（g/kw ·h）： | Fuel Consumption | ≤0.395 |
| 油箱容量（L）： | Fuel Tank capacity | 3.6 |
| 机油容量（L）： | Engine oil capacity | 0.6 |
|
Weight |
||
| 机体重量（KG）： | Total Weight | 414 |
| 最大载重（KG）： | Max loading weight | 500 |
| 机体尺寸（MM）：
不含脚踏板不含铲斗 |
Machin size （ Without pedal, without bucket） | 1570*880*1300 |
| 含脚踏板铲斗尺寸（MM）： | Bucket size with foot pedal: | 2050*880*1300 |
| 货箱尺寸（MM）： | Container size： | 1050*730*730 |
| 底盘宽度（MM）： | Chassis width： |
700 |
|
Track data |
||
| 履带宽度（MM）： | track width： | 180 |
| 履带接地长度（MM）： | Track grounding length： | 1000 |
| 底盘离地间隙（MM）： | Chassis ground
clearance: |
110 |
|
Hopper |
||
| 货箱容量（dm³) | Cargo box Capacity | 200 |
| 翻斗方式： | Tipping Systme | Hydraulic Tipper |
| 翻斗角度 ( ° ) : | Tilting Angle | 90 |
| 卸料离地高度（MM）： | Unloading height above ground | 260 |
|
Walk |
||
| 行走性能速度（km/h）： | Walking Speed | 2.88 |
| 最小回转半径（m）： | Minimum Turning radius | 1.15 |
| 履带中心距（mm）： | Track gauge | 520 |
| 底盘离地间隙（mm）： | Chassis ground
clearance： |
100 |
| 爬坡能力 ( ° ) : | Climbing a billty | 20 |
|
Hydraulic oil |
||
| 液压油品号： | Hydraulic oil model | 46 # Anti-wear Hydraulic Oil |
| 液压油箱容量（L）： | Hydraulic tank capacity | 8.2 |
| 发动机选配 | ||
| 发动机型号： | 排放 | 马力/转速 rpm |
| 科普 173（柴油） | 欧五 | 5.5HP/3600 |
| 润通（手拉启动） | EPA/欧五 | 7HP/3600 |
A: We are a professional manufacture , we have our own R&D team and sales team, we provide one-stop service.
A: Yes, offer us necessary information, we provide custom-make service to meet different needs of global clients with different budgets.
A: Yes, we support mass production. We can support customization (one piece is enough), but we can’t provide free samples.
A: Accepted Delivery Terms: FOB,CFR,CIF,EXW;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese,Spanish Other customizable options
RuntoMEC’s team is online 24 hours a day to answer your questions. Reach out immediately to find the perfect Mini Dumper machine for your business.
